2S-PA with Missing Data
Mark Lai
2026-08-30
missing-data.RmdWith missing data, two things change in two-stage path analysis.
Stage 1 must be fitted with a missing-data method
(missing = "fiml" in lavaan), and each case is
then scored on its own observed indicators, so the score
standard errors, implied loadings, and error variances are
per-row quantities rather than one pooled matrix. And
stage 2 has to use those per-row values: tspa() (the
lavaan backend) reduces the per-pattern values to a single
representative matrix (reduce =), whereas
tspa_mx_model() (the OpenMx backend) carries
the per-row values through definition variables, and its raw-data FIML
evaluation can also handle rows whose scores are dropped as
NA. The stage-2 fits in this vignette therefore use
tspa_mx_model().
For illustration, we create two missing data patterns on
PoliticalDemocracy: (1) MCAR missingness in a single item
(x1, about 30% of cases); (2) block missingness, where the
last 10 cases are missing all four dem65 indicators — a
factor with no observed indicator at all.
Single-Factor Model
set.seed(2225)
library(lavaan)
#> This is lavaan 0.7-2
#> lavaan is FREE software! Please report any bugs.
library(R2spa)
library(OpenMx)
#> To take full advantage of multiple cores, use:
#> mxOption(key='Number of Threads', value=parallel::detectCores()) #now
#> Sys.setenv(OMP_NUM_THREADS=parallel::detectCores()) #before library(OpenMx)
data(PoliticalDemocracy)
pd2 <- PoliticalDemocracy
# Add MCAR missing data to x1 (about 30% of the 75 cases)
pd2[!rbinom(75, size = 1, prob = 0.7), "x1"] <- NAFactor scores with lavaan::lavPredict():
fit <- cfa("ind60 =~ x1 + x2 + x3", data = pd2, missing = "fiml")
fs_lavaan <- lavPredict(fit, method = "Bartlett", se = TRUE, fsm = TRUE)
# From R2spa
fs <- R2spa::get_fs(fit, method = "Bartlett")
# One SE per missing-data pattern
round(table(pattern = attr(fs, "fs_pattern")[[1]]$label,
se = fs$fs_ind60_se), 4)
#> se
#> pattern 0.149802246676676 0.179196081489146
#> x1+x2+x3 48 0
#> x2+x3 0 27
# Compare factor scores
plot(fs_lavaan, fs$fs_ind60)
abline(a = 0, b = 1)
Because each case is scored conditionally on its own observed
indicators, get_fs() returns per-row standard errors and
error variances: the 48 complete cases (pattern "x1+x2+x3")
get SE 0.150, and the 27 cases observed only on x2 and
x3 get SE 0.179. The
fsT/fsL/fsb/scoring_matrix
attributes are correspondingly lists with one entry per
pattern, and the fs_pattern attribute maps each row to its
pattern. The plot confirms that the R2spa scores reproduce
lavPredict() exactly.
Multiple group
mg_fit <- cfa("ind60 =~ x1 + x2 + x3",
data = cbind(pd2, group = rep(1:2, c(40, 35))),
missing = "fiml",
group = "group"
)
mg_fs <- R2spa::get_fs(mg_fit)
head(mg_fs, 10)
#> fs_ind60 fs_ind60_se ind60_by_fs_ind60 ev_fs_ind60 group
#> 1 -0.629900908 0.06327411 0.9907469 0.004003613 1
#> 2 -0.003598338 0.06481599 0.9902860 0.004201113 1
#> 3 0.531624709 0.06327411 0.9907469 0.004003613 1
#> 4 1.093155269 0.06481599 0.9902860 0.004201113 1
#> 5 0.751323885 0.06481599 0.9902860 0.004201113 1
#> 6 0.032310438 0.06481599 0.9902860 0.004201113 1
#> 7 -0.001195823 0.06327411 0.9907469 0.004003613 1
#> 8 -0.081264245 0.06481599 0.9902860 0.004201113 1
#> 9 0.087672535 0.06327411 0.9907469 0.004003613 1
#> 10 0.158894033 0.06327411 0.9907469 0.004003613 1
# Both groups contain the same two patterns
lapply(attr(mg_fs, "fs_pattern"), function(p) table(p$label))
#> $`1`
#>
#> x1+x2+x3 x2+x3
#> 25 15
#>
#> $`2`
#>
#> x1+x2+x3 x2+x3
#> 23 12The multigroup result is a single data frame with a
group column, and each group’s
fsT/fsL/fsb/scoring_matrix
attribute is itself a per-pattern list.
Multiple-Factor Model
The measurement model constrains the two factors’ loadings to be
equal (labels a–d) and adds covariances
between the corresponding indicators:
# Make last 10 cases completely missing on y5-y8 (all dem65 indicators)
pd2[66:75, c("y5", "y6", "y7", "y8")] <- NA
fit2 <- cfa("
dem60 =~ a * y1 + b * y2 + c * y3 + d * y4
dem65 =~ a * y5 + b * y6 + c * y7 + d * y8
y1 ~~ y5
y2 ~~ y6
y3 ~~ y7
y4 ~~ y8
", data = pd2, missing = "fiml")This block-missing pattern is the hard case: for the 10 affected
rows, dem65 has no observed indicator at all.
Regression scores
With regression (EBM) scores, the dem65 score is still
defined for those rows — regression scoring uses the
cross-factor covariances, so dem65 is imputed from the
dem60 indicators. But the per-row measurement information
is degenerate: the implied loading of the score on dem65 is
0, i.e. the score carries no information about dem65, so
measurement-error correction is impossible. We therefore drop those
dem65 scores; OpenMx’s raw-data FIML then fits those rows
from the structural model alone.
# Obtain tidy-ed factor scores data
fs_dat <- R2spa::augment_lav_predict(fit2)
# Per-row definition-variable matrices: each cell names the `fs_dat` column
# carrying that case's loadings / error variances (the exact, per-row
# correction that `tspa()`'s `reduce = ` pooling only approximates).
cross_load <- matrix(c(
"dem60_by_fs_dem60", "dem60_by_fs_dem65",
"dem65_by_fs_dem60", "dem65_by_fs_dem65"
), nrow = 2) |>
`dimnames<-`(list(c("fs_dem60", "fs_dem65"), c("dem60", "dem65")))
err_cov <- matrix(c(
"ev_fs_dem60", "ecov_fs_dem60_fs_dem65",
"ecov_fs_dem60_fs_dem65", "ev_fs_dem65"
), nrow = 2) |>
`dimnames<-`(rep(list(c("fs_dem60", "fs_dem65")), 2))
# Drop the non-correctable dem65 scores of the 10 all-missing rows;
# OpenMx's raw-data FIML then fits those rows as usual.
fs_dat[66:75, "fs_dem65"] <- NA
tspa_mx <- tspa_mx_model(
"dem65 ~ dem60; dem65 + dem60 ~ 1",
data = fs_dat,
fsL = cross_load, fsT = err_cov,
fsb = c(fs_dem60 = "int_fs_dem60", fs_dem65 = "int_fs_dem65")
)
#> Running m1 with 5 parameters
# Run OpenMx
tspa_mx_fit <- mxRun(tspa_mx)
#> Running m1 with 5 parameters
# Summarize the results
summary(tspa_mx_fit)
#> Summary of m1
#>
#> free parameters:
#> name matrix row col Estimate Std.Error A
#> 1 m1.A[4,3] A dem65 dem60 9.125862e-01 0.0715752
#> 2 m1.S[3,3] S dem60 dem60 4.559668e+00 0.8414167
#> 3 m1.S[4,4] S dem65 dem65 5.369811e-01 0.2310376
#> 4 m1.M[1,3] M 1 dem60 -4.568894e-08 0.2621047
#> 5 m1.M[1,4] M 1 dem65 -5.709867e-08 0.1421203
#>
#> Model Statistics:
#> | Parameters | Degrees of Freedom | Fit (-2lnL units)
#> Model: 5 135 404.9387
#> Saturated: 5 135 NA
#> Independence: 4 136 NA
#> Number of observations/statistics: 75/140
#>
#> Information Criteria:
#> | df Penalty | Parameters Penalty | Sample-Size Adjusted
#> AIC: 134.9387 414.9387 415.8083
#> BIC: -177.9222 426.5261 410.7675
#> To get additional fit indices, see help(mxRefModels)
#> timestamp: 2026-08-30 12:27:06
#> Wall clock time: 0.02846885 secs
#> optimizer: SLSQP
#> OpenMx version number: 2.22.11
#> Need help? See help(mxSummary)The per-row measurement values reach OpenMx as definition
variables: fsL and fsT are character
matrices whose cells name the fs_dat column holding that
case’s value, so the stage-2 correction is per-row rather than pooled.
fsb does the same for the per-row measurement intercepts
(the int_* columns; a FIML fit estimates a mean structure,
so the intercepts vary with the missing-data pattern).
Bartlett scores
Bartlett scoring does not use the cross-factor covariances, so for
the 10 rows with no observed dem65 indicator the score is
NA by convention — in contrast to the EBM case above, where
the score was defined but non-correctable and had to be dropped.
# Obtain tidy-ed factor scores data (Bartlett weights)
fsb_dat <- augment_lav_predict(fit2, method = "Bartlett")
# fsb_dat[66:75, "fs_dem65"] is already NA (no observed indicator);
# stated explicitly to mirror the EBM case
fsb_dat[66:75, "fs_dem65"] <- NA
tspab_mx <- tspa_mx_model(
"dem65 ~ dem60; dem65 + dem60 ~ 1",
data = fsb_dat,
fsL = cross_load, fsT = err_cov,
fsb = c(fs_dem60 = "int_fs_dem60", fs_dem65 = "int_fs_dem65")
)
#> Running m1 with 5 parameters
# Run OpenMx
tspab_mx_fit <- mxRun(tspab_mx)
#> Running m1 with 5 parameters
# Summarize the results
summary(tspab_mx_fit)
#> Summary of m1
#>
#> free parameters:
#> name matrix row col Estimate Std.Error A
#> 1 m1.A[4,3] A dem65 dem60 9.125862e-01 0.07157514
#> 2 m1.S[3,3] S dem60 dem60 4.559668e+00 0.84138958
#> 3 m1.S[4,4] S dem65 dem65 5.369811e-01 0.23103931
#> 4 m1.M[1,3] M 1 dem60 -4.578959e-08 0.26210338
#> 5 m1.M[1,4] M 1 dem65 -5.290055e-08 0.14212079
#>
#> Model Statistics:
#> | Parameters | Degrees of Freedom | Fit (-2lnL units)
#> Model: 5 135 536.4213
#> Saturated: 5 135 NA
#> Independence: 4 136 NA
#> Number of observations/statistics: 75/140
#>
#> Information Criteria:
#> | df Penalty | Parameters Penalty | Sample-Size Adjusted
#> AIC: 266.42127 546.4213 547.2908
#> BIC: -46.43962 558.0087 542.2500
#> To get additional fit indices, see help(mxRefModels)
#> timestamp: 2026-08-30 12:27:06
#> Wall clock time: 0.01627207 secs
#> optimizer: SLSQP
#> OpenMx version number: 2.22.11
#> Need help? See help(mxSummary)Compared to Joint Model
The gold-standard reference is the joint model, which fits the measurement and structural parts simultaneously under FIML:
jfit <- sem("
dem60 =~ a * y1 + b * y2 + c * y3 + d * y4
dem65 =~ a * y5 + b * y6 + c * y7 + d * y8
y1 ~~ y5
y2 ~~ y6
y3 ~~ y7
y4 ~~ y8
dem65 ~ dem60
", data = pd2, missing = "fiml")
summary(jfit)
#> lavaan 0.7-2 ended normally after 53 iterations
#>
#> Estimator ML
#> Optimization method NLMINB
#> Number of model parameters 29
#> Number of equality constraints 3
#>
#> Number of observations 75
#> Number of missing patterns 2
#>
#> Model Test User Model:
#>
#> Test statistic 27.499
#> Degrees of freedom 18
#> P-value (Chi-square) 0.070
#>
#> Parameter Estimates:
#>
#> Standard errors Standard
#> Information Observed
#> Observed information based on Hessian
#>
#> Latent Variables:
#> Estimate Std.Err z-value P(>|z|)
#> dem60 =~
#> y1 (a) 1.000
#> y2 (b) 1.337 0.153 8.738 0.000
#> y3 (c) 1.182 0.132 8.942 0.000
#> y4 (d) 1.334 0.136 9.777 0.000
#> dem65 =~
#> y5 (a) 1.000
#> y6 (b) 1.337 0.153 8.738 0.000
#> y7 (c) 1.182 0.132 8.942 0.000
#> y8 (d) 1.334 0.136 9.777 0.000
#>
#> Regressions:
#> Estimate Std.Err z-value P(>|z|)
#> dem65 ~
#> dem60 0.913 0.074 12.357 0.000
#>
#> Covariances:
#> Estimate Std.Err z-value P(>|z|)
#> .y1 ~~
#> .y5 0.627 0.395 1.587 0.113
#> .y2 ~~
#> .y6 1.238 0.765 1.618 0.106
#> .y3 ~~
#> .y7 1.534 0.695 2.207 0.027
#> .y4 ~~
#> .y8 0.200 0.551 0.363 0.716
#>
#> Intercepts:
#> Estimate Std.Err z-value P(>|z|)
#> .y1 5.465 0.298 18.348 0.000
#> .y2 4.256 0.442 9.629 0.000
#> .y3 6.563 0.397 16.534 0.000
#> .y4 4.453 0.379 11.733 0.000
#> .y5 5.181 0.313 16.561 0.000
#> .y6 2.782 0.403 6.899 0.000
#> .y7 6.249 0.367 17.043 0.000
#> .y8 3.996 0.383 10.420 0.000
#>
#> Variances:
#> Estimate Std.Err z-value P(>|z|)
#> .y1 2.093 0.490 4.276 0.000
#> .y2 6.502 1.252 5.195 0.000
#> .y3 5.443 1.038 5.242 0.000
#> .y4 2.689 0.716 3.756 0.000
#> .y5 2.528 0.551 4.588 0.000
#> .y6 3.677 0.827 4.446 0.000
#> .y7 3.386 0.760 4.453 0.000
#> .y8 2.628 0.702 3.745 0.000
#> dem60 4.560 1.038 4.394 0.000
#> .dem65 0.537 0.258 2.085 0.037
# The three estimates of the dem65 ~ dem60 path:
c(EBM.mx = coef(tspa_mx_fit)["m1.A[4,3]"],
Bartlett.mx = coef(tspab_mx_fit)["m1.A[4,3]"],
joint = coef(jfit)["dem65~dem60"])
#> EBM.mx.m1.A[4,3] Bartlett.mx.m1.A[4,3] joint.dem65~dem60
#> 0.9125862 0.9125862 0.9125862Both 2S-PA fits (regression and Bartlett scores) recover the
dem65 ~ dem60 path at 0.913, identical to the joint-model
estimate to four decimal places.
Multiple group
The same pipeline applies to multigroup fits:
augment_lav_predict() returns a list with one tidy-ed data
frame per group, each carrying that group’s per-row values. All 10
block-missing rows fall in group 2, so only group 2 contains the pattern
with no observed dem65 indicator. (lavaan
warns that a single label used in a multigroup fit imposes cross-group
equality — that is intentional here: a–d are
constrained equal in both groups.)
mg_fit2 <- cfa("
dem60 =~ a * y1 + b * y2 + c * y3 + d * y4
dem65 =~ a * y5 + b * y6 + c * y7 + d * y8
y1 ~~ y5
y2 ~~ y6
y3 ~~ y7
y4 ~~ y8
",
data = cbind(pd2, group = rep(1:2, c(40, 35))),
missing = "fiml", group = "group"
)
#> Warning: lavaan->lav_model_pt():
#> using a single label per parameter in a multiple group setting implies
#> imposing equality constraints across all the groups; If this is not
#> intended, either remove the label(s), or use a vector of labels (one for
#> each group); See the Multiple groups section in the man page of
#> model.syntax.
mg_out <- get_fs(mg_fit2)
head(mg_out)
#> fs_dem60 fs_dem65 fs_dem60_se fs_dem65_se dem60_by_fs_dem60
#> 1 -2.8000738 -2.3481803 0.4602081 0.484165 0.7056551
#> 2 -3.0162173 -1.6560141 0.4602081 0.484165 0.7056551
#> 3 2.6733722 3.0172082 0.4602081 0.484165 0.7056551
#> 4 2.4571381 2.4920427 0.4602081 0.484165 0.7056551
#> 5 1.3378821 1.3982512 0.4602081 0.484165 0.7056551
#> 6 0.1326308 -0.4178734 0.4602081 0.484165 0.7056551
#> dem60_by_fs_dem65 dem65_by_fs_dem60 dem65_by_fs_dem65 ev_fs_dem60
#> 1 0.2749477 0.2331707 0.681784 0.2117915
#> 2 0.2749477 0.2331707 0.681784 0.2117915
#> 3 0.2749477 0.2331707 0.681784 0.2117915
#> 4 0.2749477 0.2331707 0.681784 0.2117915
#> 5 0.2749477 0.2331707 0.681784 0.2117915
#> 6 0.2749477 0.2331707 0.681784 0.2117915
#> ecov_fs_dem65_fs_dem60 ev_fs_dem65 group
#> 1 0.1496662 0.2344158 1
#> 2 0.1496662 0.2344158 1
#> 3 0.1496662 0.2344158 1
#> 4 0.1496662 0.2344158 1
#> 5 0.1496662 0.2344158 1
#> 6 0.1496662 0.2344158 1
